Camden EC1
Preamp,
Signal Processor & Headphone Amplifier
Award-winning Preamp Performance
Schließen Sie Camden EC1 an Ihr Audio-Interface an und erleben Sie den preisgekrönten Sound des Camden Preamp-Designs. Mit bis zu 68,5 dB makellosem, sauberem Gain ist der Camden EC1 der perfekte Vorverstärker für die Kombination mit dynamischen Mikrofonen und Bändchenmikrofonen mit geringer Verstärkung.
Powerful Headphone Monitoring
Mit einem leistungsstarken Kopfhörerverstärker in Referenzqualität und einem dedizierten Line-Mixer bietet Ihnen Camden EC1 ein WAHRES, latenzfreies Monitoring Ihres Vorverstärkers in Mastering-Qualität, das mühelos mit der Wiedergabe von Ihrer DAW gemischt wird.
Könnte der erste Vorverstärker sein, den Sie jemals kaufen werden, und möglicherweise der letzte.
Preislich ist es Ihr erster Vorverstärker, aber der einzige Vorverstärker, den Sie jemals brauchen werden. Erstklassige technische Exzellenz zu Hause in jedem professionellen Studio, geliefert zu Ihrem Studio für weniger als Sie vielleicht denken.
Ultra-sauber und transparent
Nehmen Sie Ihr Mikrofon, Ihre Linie und Ihre Instrumente mit vollständiger Transparenz auf; Verstärken Sie dynamische Mikrofone mit geringer Empfindlichkeit, ohne Rauschen hinzuzufügen; und erfassen Sie sofortige Spitzen ohne Phasenverschiebungen, die das Mischen erschweren.
Mit Vintage-Mojo on Tape
Auf Knopfdruck nimmt der cleane Camden-Vorverstärker mit seinem analogen Mojo-Sättigungsregler und den „Thump“- und „Cream“-Stilen die Rolle von Vintage-Übertrager- oder Röhrenvorverstärkern an.
Perfekt für Musiker, Ingenieure, Podcaster, Synchronsprecher
-
All specifications are typical performance unless otherwise noted. All specifications are subject to change at any time. Tested with Audio Precision APx555.
Preamp
Test Signal Path -
APx555 (Line Out) - Input 1 - Line Output - APx555 (Line In)
Input Impedance -
Mic= 8.9 kOhms 48v Off, 5.4 kOhms 48v ON,
-
Line = 24.3 kOhms,
-
Hi-Z= 1.5 MOhm Unbalanced, 3 MOhm Balanced
Max Input Level -
Mic = +17.6dBu (<0.003% THD),
-
Line = +26.5dBu (<0.02% THD),
-
Hi-Z = +24dBu (<0.02% THD)
Minimum Gain -
Mic= 8dB, Line = 0dB, Hi-Z = 3dB
Maximum Gain -
Mic = 68dB, Line = 60dB, Hi-Z = 63dB
Equivalent Input Noise (EIN) -
<-129.5dBu (150 Ohm source, unweighted),
-
<-131dBu (150 Ohm source, A-weighted),
-
<-135.5dBu (Inputs common, unweighted)
Frequency Response -
±0.7dB (<1 Hz to >1000 kHz, Min Gain),
-
±0.7dB (<1 Hz to >1000 kHz, 35dB Gain),
-
±1dB (<1.5 Hz to 900 kHz, 63dB Gain),
-
±1dB (<5 Hz to >200 kHz, Max Gain)
Phase Shift -
<2.75° (20Hz to 20kHz, 40dB Gain),
-
<4° (20Hz to 20kHz, 63dB Gain),
-
<6° (20Hz to 20kHz, Max Gain)
THD+N -
<0.00025% (1kHz, 35dB Gain, +24dBu out)
Intermodulation Distortion -
<0.0006% (50Hz and 7kHz, 35dB gain, +20dBu out),
-
<0.0005% (50Hz and 7kHz, 35dB gain, +15dBu out)
Hi-Pass Filter (HPF) -
80Hz, -3dB, 12dB/Oct
CMRR -
>70dB, typ >85dB, 35dB gain, 10-20kHz, 100mV Common mode
Slew Rate -
20V/uS, 35dB gain, +25dBu out
48v LED Thresholds -
Off = 48v Off, voltage fully discharged
-
Amber = 48v voltage charging/discharging
-
Red = 48v fully charged
Signal LED Meter Thresholds -
Blue = -20dBu
-
Green = -12dBu
-
Amber = +21dBu
-
Red = +24dBu
Max Output Level -
Balanced XLR = +27.5dBu (<0.002% THD, 30dB Gain)
Impedance Balanced -
¼” Jack = +21.5dBu (<0.002% THD, 30dB Gain)
Output Impedance -
Balanced XLR = 150 Ohm
Impedance Balanced -
1/4” Jack = 150Ohm Balanced, 75 Ohm Unbalanced
Link Max Output Level -
Impedance Balanced 1/4” Jack = +21.8dBu (<0.006% THD)
Link Output Impedance -
Impedance Balanced 1/4” Jack = 75 Ohm Unbalanced, 150 Ohm Balanced (Buffered Output)
Headphone Amplifier
Test Signal Path
APx555 (Line Out) - AUX Input - Headphone Output - APx555 (Line In)
Frequency Response
-1dB, <1Hz to >70kHz
THD
<0.0006% (-104.4dB) @ +20dBu, 1kHz, A-weighted, 300 Ohm load
THD+N
<0.00085% (-101.4dB) @ +20dBu, 1kHz, A-weighted, 300 Ohm load
Output Impedance
0.33 Ohms
Output Wattage
250mW x 2 @ 600 Ohms, 1kHz
650mW x 2 @ 220 Ohms, 1kHz
1.21W x 2 @ 100 Ohms, 1kHz
500mW x 2 @ 32 Ohms, 1kHz
Dynamic Range
114.5dB A-weighted, AES17 method, 20Hz - 20kHz, 300 Ohm load
Noise Floor
-93.5dBu A-weighted, 20Hz - 20kHz, 300 Ohm load
Power
AC Requirements
100V – 240V AC, 50 – 60 Hz
Total Power Consumption
24v, 1.25A DC, 30W
(Rackmount Kit Available)





- Discrete mic/line/hi-z preamp featuring the award-winning ‘Camden’ topology from the Camden 500 Preamp and Signal Processor for 500 series
- Audio performance at the near-theoretical limits of noise, distortion, and phase/frequency linearity at all gain settings
- EIN: <-129.5dBu, 150 Ohm source, unweighted, <-135.5dBu, Inputs common, unweighted
- THD+N: <0.00025% (1kHz, 35dB gain, +24dBu out)
- Intermodulation Distortion: <0.0006% (50Hz and 7kHz, 35dB gain, +20dBu out)
- Phase Shift: <2.75° (20Hz to 20kHz, 40dB gain), <6° (20Hz to 20kHz, Max Gain)
- Freq. Response: ±0.7dB (<1 Hz to >1000 kHz, 35dB gain), ±1dB (<5 Hz to >200 kHz, Max Gain)
- Unique 48v status LED
- 48v LED Lights Orange to indicate voltage charging or dissipating to prevent damage to ribbon microphones and to ensure voltage is fully charged before use
- 48v LED lights RED when voltage is fully charged and ready to use
- ‘Mojo’ analogue saturation circuits with variable control, true bypass, and 2 discrete styles - Thump and Cream
- Thump excites low-end content by boosting lower odd/even harmonics from a range of 160Hz to 20Hz and below
- Cream boosts odd/even harmonics whilst also reducing the amplitude of the fundamental frequencies and applying typical transformer-style transient taming
- Discrete headphone mixers with independant CH 1, Ext Input, and Aux Input level controls
- Monitor the Camden preamp directly with headphones during mic placement to find the sweet spot of the instrument/source
- Create zero-latency artist mixes by combining the Camden preamp with external playback from Aux Input 1/4” jacks on Camden EC1’s rear panel
- Use the reference grade headphone amplifier for critical listening by sending stereo mixes from the interface into the Aux input and monitoring directly using Camden EC1’s headphone output
- Reference-quality, high-powered headphone amplifier
- Freq. Response: <±1dB, <1 Hz to >100 kHz
- Output Impedance: 0.33 Ohms
- THD: 0.0003%, 1kHz
- Output Wattage: 2x250mW @ 600 Ohm, 2x450mW @ 220 Ohm, 2x250mW @ 100 Ohm
- Balanced XLR output and impedance balanced 1/4” jack outputs for maximum connectivity into audio interfaces and other downstream equipment
- -10dB PAD to attenuate preamp output for lowheadroom audio interfaces
- Dedicated Impedance balanced 1/4" jack Link output for true instrument DI functionality and splitting instrument inputs to balanced or unbalanced amplifiers and effects
- C.A.S.T. OUT port for connecting into 500R8/500ADAT
- Transmit Camden EC1’s preamp and Ext Input directly into 500R8 and 500ADAT’s 500 series modules inputs for recording/processing
- Receive a stereo mix generated from 500R8/500ADAT and monitor using Camden EC1’s headphone mixer
- All managed and distributed via a single shielded Cat 5e, Cat 6, or Cat 7 cable
- External high-current 24v, 1.25a power supply with latching connector
